Specifications:
Accuracy Class: Class III (eqv. to OIML R76)
Internal Resolution: 1 000 000 counts
Measurement Rate: 10 measurements/s
Loadcell Excitation Voltage: 5.00±3% Vdc (typ.)
AC Power Voltage: 110/120 or 220/240 Vac / 50~60 Hz
Battery Life: 50 ~ 130 hours (typ.)
Operating Temperature: -10 ~ +40 degC (+14 ~ +104 degF)
Operating Humidity: 0 ~ 90 % (rel.) at 20 degC
Indicator Net Weight: 1.90 kg (4.20 lb)
Features:
SS304 stainless steel housing and bracket
IP65 (eqv.) insulation protection
1.0inch/25.4mm high contrast LED/LCD display
7-key flat membrane panel
Drives up to 8x350ohm loadcells
Built-in 6V/4.0Ah rechargeable battery
2 configurable user-defined function keys
2 configurable software set-points
Full duplex RS-232 communication port
Options:
Measurement unit switch function (m)
Preset tare function (t)
Calibration switch with seal protection (S)
Real-time clock with backup battery (C)
RS-485 communication port (8)
Two relays for set-point logic output (R)
Extended serial interface printer (P)
RF kits for RF scoreboard or RF transmitter (F)
Bluetooth BLE 4.0 for cellphone, pad & PC (B)
