Specifications:
Accuracy Class: Class III (eqv. to OIML R76)
Internal Resolution: 1 000 000 counts
Measurement Rate: 10 measurements/s
Loadcell Excitation Voltage: 3.00±3% Vdc (typ.)
AC Power Voltage: 94~121 or 187~242 Vac / 50~60 Hz
Battery Life: 50 ~ 130 hours (typ.)
Operating Temperature: -10 ~ +40 degC (+14 ~ +104 degF)
Operating Humidity: 0 ~ 90 % (rel.) at 20 degC
Indicator Net Weight: 1.55 kg (3.40 lb)
Features:
ABS plastic housing and stainless steel bracket
6-digit 1.2inch/30mm high-intensity LED display
6-digit 1.6inch/40mm LCD display with backlight
6-key flat tact switch keypad
Drives up to 4x350ohm loadcells
Built-in 6V/4.0Ah rechargeable battery
1 configurable user-defined function keys
2 configurable software set-points
Full duplex RS-232 communication port
Options:
Measurement unit switch function (m)
Preset tare function (t)
Calibration switch with seal protection (S)
Real-time clock with backup battery (C)
RS-485 communication port (8)
Extended serial interface printer (P)
RF kits for RF scoreboard or RF transmitter (F)
